» DVM Test Report: Ac Analysis|Conducted Susceptibility|Vin Nominal|Light Load
| Test Details | |
| Schematic | LTC3406B - DVM ADVANCED.sxsch |
| Test | Ac Analysis|Conducted Susceptibility|Vin Nominal|Light Load |
| Date / Time | 5/23/2011 15:13:07 PM |
| Report Directory | DVM_REPORTS\2011-05-23-15_12_01_PM\Ac Analysis\Conducted Susceptibility\Vin Nominal\Light Load |
| Log File | report.txt |
| Status | PASS |
| Simulator | simplis |
| Deck | input.deck |
| Init | input.deck.init |
| Measured Scalar Values | |
| min_reject1_gain | -74.6785 |
| max_reject1_gain | -41.389 |
| min_reject1_gain_freq | 1k |
| max_reject1_gain_freq | 15.8489k |
| min_reject1_phase | -450.248 |
| max_reject1_phase | -61.6245 |
| min_reject1_phase_freq | 891.251k |
| max_reject1_phase_freq | 1k |
| sw_freq | 955.703k |
| FREQUENCY | AVG 100.286m MIN 0 MAX 5 RMS 708.117m |
| ILOAD1 | AVG 50.0255m MIN 49.9695m MAX 50.0749m RMS 50.0255m |
| ISRC1 | AVG 16.4304m MIN 313.482u MAX 500.173m RMS 49.4701m |
| VLOAD1 | AVG 1.50569 MIN 1.504 MAX 1.50717 RMS 1.50569 |
| VSRC1 | AVG 4.99998 MIN 4.9995 MAX 5 RMS 4.99998 |
| Measured Spec Values | |
| min_vout1 | PASS: Min. Output1 Voltage (1.504) is greater than or equal to Min. Output1 Voltage Spec (1.42975) |
| max_vout1 | PASS: Max. Output1 Voltage (1.50717) is less than or equal to Max. Output1 Voltage Spec (1.58025) |
 SUSCEPTIBILITY
REJECT PH
REJECT MAG
|
|
| SXGPH File | simplis_ac47_2840.sxgph |
 SRC1
ISRC1
VSRC1
|
|
| SXGPH File | simplis_pop33_2821.sxgph |
 LOAD1
VLOAD1
ILOAD1
|
|
| SXGPH File | simplis_pop33_2826.sxgph |
 default
FREQUENCY
|
|
| SXGPH File | simplis_pop33_2804.sxgph |
| Other SXGPH Files | |
| clock#pop | simplis_pop33_2809.sxgph |
